Automatic Inline Pallet Wrapping Machine – Extrema

Item No.85.C39055.01
​​​​The Extrema Pallet Wrapping Machine is used to integrate into automatic packaging lines, most suited for medium to high volume production lines. The fully automatic wrapping functions mirror the Superplus that is engineered to reduce wrapping costs and increase warehouse efficiency. Operating at 12 rotations per minute, the Extrema has the capacity to wrap up to 40 pallets per hour. The automation features and customised options for this machine are endless.​​​​
Machine Specification
   Height: 2,466mm
   Width: 2,200mm
   Length: 2,880mm
   Conveyor height: 76mm
   Machine weight: 850kg
   Power supply: 400 VAC 3PH + N VAC 3PH + N
   Power absorption: 4kW
   Maximum rotation speed: 16rpm
   Pallet/hour: 35-50
5 and 10 year warranty available.
*Additional features available. ​​​​​

Extrema pallet wrapping machine video

Specifications and extra options

Product specifications

  • The automatic cycle includes loading the pallet, film hooking, pallet wrapping, film cold cutting, hot sealing of cut edge, and unloading of the pallet.
  • Air device for the blow of the edge of the film cut by the pliers.
  • Roller conveyor on the turntable.
  • Power pre-stretch carriage.
  • Frequency controller for carriage speed adjustment.
  • Frequency controller for turntable speed adjustement.
  • Loading plate ø2,200mm.
  • Maximum height of pallet: 2,200mm.
  • Maximum size of the pallet: 1,200 x 1,200mm.
  • Maximum loading weight: 2,000 kg.
  • Power board IP54.
  • Photocell for pallet height detection.
  • Safety stop at the base of the carriage.
  • Stop at 0 position.
  • Lock password (parameters values can be modified only entering a password).
  • Adjustable parameters by the control panel: cycle selection, bottom laps, top laps, topsheet cycle parameters, rotation speed, carriage ascent speed, carriage descent speed, film tension.
  • 3 working cycles: ascent/descent; topsheet; layers.
  • Storage of 10 end user programs.
  • 4 working modes: semi manual, semi automatic, fixed height; automatic.
  • Strenghtening operation.
  • Acoustic warning at the cycle beginning and stop.
  • Auto diagnostic.
  • Wrapped pallet counter.
  • Powder coating.
  • Braked turntable at the end of the cycle.

Extra options

  • – Adjustable power pre-stretch.
  • – Power pre-stretch with auto cut-off system.
  • – Roping system.
  • – 3,000mm max. wrapping height.
  • – Ramp.
  • – Photocell for dark loads.
  • – Antistatic rollers.
  • – Film edge rollers to improve load containment force.

Video

OUR CLIENTS

We’ve helped many of our customers save costs and usage on their stretch wrap film and plastic waste. Read how we’ve been able to make real impacts on their businesses in our selection of case studies.

Get in touch

Fill out the form below and an Omni Group packaging specialist will contact you to arrange an assessment.
Image slider

Automatic Inline Pallet Wrapping Machine – Extrema

Item No.85.C39055.01
Rent from (per month):​​​​​
Price $0
Machine specifications:
Height: 2,466mm
Width: 2,200mm
Length: 2,880mm
Machine weight: 850kg
Power supply: 400 VAC 3PH + N VAC 3PH + N
Power absorption: 4kW
Max. rotation speed: 16 rpm
Pallets/hour: 35-50
The Extrema, an advanced, fully automatic inline pallet wrapping machine, is designed to integrate into medium to high-volume production lines. The fully automatic wrapping functions mirror the Superplus engineered to reduce wrapping costs and increase warehouse efficiency. Operating at 12 rotations per minute, the Extrema can wrap up to 40 pallets per hour. The Extrema automatic inline pallet wrapping machine has many automation features and customizable options, allowing you to tailor the machine to your specific requirements.

AWARD-WINNING PALLET WRAP SOLUTION

SPECIFICATIONS AND EXTRA OPTIONS

SPECIFICATIONS

  • The automatic cycle includes loading the pallet, film hooking, pallet wrapping, film cold cutting, hot sealing of cut edge and unloading of the pallet.
  • Air device to blow up the initial film tail.
  • Roller or chain conveyor on the turntable.
  • Power pre-stretch carriage.
  • PLC for management of the wrapping cycle.
  • Frequency controller for carriage speed adjustment.
  • Frequency controller for turntable speed adjustement.
  • Turntable: 2,000mm.
  • Maximum height of pallet: 2,100mm.
  • Maximum size of the pallet: 1,200 x 1,200mm.
  • Maximum loading weight: 2,000kg.
  • Power board ip54.
  • Photocell for pallet height detection.
  • Safety stop at the base of the carriage.
  • Stop at home position.
  • 3 password levels (including lock password).
  • Adjustable parameters by the control panel without password: cycle selection, bottom laps, top laps, topsheet cycle parameters, rotation speed, carriage ascent speed, carriage descent speed, film tension, starting wrapping height.
  • 3 working cycles: ascent/descent; topsheet; layers.
  • Storage of 32 end user programs.
  • Strenghtening operation.
  • Auto diagnostic.
  • Wrapped pallet counter.
  • Powder coating.
  • Braked turntable at the end of the cycle.

EXTRA OPTIONS

  • Adjustable power pre-stretch.
  • Power pre-stretch with auto cut-off system.
  • Roping system.
  • Increased maximum wrapping height.
  • Photocell for dark loads.
  • Antistatic rollers.
  • Film edge rollers to improve load containment force.
