Base Pallet Wrapper | Power Pre-Stretch System
FUNCTION
Adjustable power pre-stretch or electromagnetic broke film tension.
Adjustable parameters: cycle selection, bottom & top laps, top sheet cycle, rotation speed, carriage ascent & descent speed, film tension, starting wrapping height.
6 working cycles: ascent/descent; top sheet; only ascent; only descent; layers; stack.
3 working modes: semi manual, semi-automatic, fixed height.
Strengthening operation.
Wrapped pallet counter.
Stop at home position.
Braked turntable at the end of the cycle.
GENERAL & SAFETY
Standard turntable diameter ø1,650mm.
Maximum height of pallet: 2,400mm.
Maximum loading weight: 2,000kg.
Powder coating.
Safety stop at the base of the carriage.
3 password levels (including lock password).
Acoustic warning for beginning and end cycle.
TECHNOLOGY
Electronic printed circuit board.
Carriage speed frequency controller.
Turntable speed frequency controller.
Photocell for pallet height detection.
Power board IP54.
Storage of 32 end user programs.
Auto diagnostic.
Receiver for infrared/radio remote control.
EXTRA OPTIONS
Top-press.
Adjustable power pre-stretch.
3,000mm max. wrapping height.
Photocell for dark loads.
Weighing system.
Mechanical system to brake roll containers.
Pre-stretch up to 420%.
Remote control.
Pit frame.
Feet under the machine.
Safety fences.
Ramp.
Film edge rollers to improve load containment force.
IP65.
The Base Pallet Wrapper is an award-winning machine that reduces plastic usage and wrapping costs. Its power pre stretch function can stretch pallet wrap film up to 400%. This increases stretch film efficiency.
This heavy-duty pallet wrapper has a chain-driven turntable and rack and pinion mast. These features reduce break downs and makes this a low maintenance and reliable machine. It includes multiple programming to ensure it wraps all pallets with optimum load containment.
We offer 5- and 10-year warranty options on this machine as well as full maintenance and servicing.
IN AUCTION: HOW OUR CLIENTS USE THIS SOLUTION.
REDUCE COTTON ON'S STRETCH WRAP CONSUMPTION AND WASTAGE.
STRETCH WRAP USAGE REDUCED BY.
25%
REDUCE AMER SPORTS' MONEY, TIME AND FIND SOLUTIONS FOR THEIR PACKAGING NEEDS.
PALLET WRAPPING COST SAVING
22%
SEE HOW OUR CLIENTS SUCCEED WITH OUR SOLUTION
REDUCE COTTON ON'S STRETCH WRAP CONSUMPTION AND WASTAGE.
Our clients have achieved impressive results using our product in real-world settings. From increasing efficiency to reducing costs, these success stories showcase the impact of our solution across different industries.
NEWS & BLOG
WHAT IS A “CUT AND WEIGH” AND WHY DO YOU NEED ONE? WE BREAK IT DOWN FOR YOU.
Put simply, it is the easiest and most effective way to measure – and therefore improve – your business’s pallet wrapping plastic consumption and output..
WHAT OUR CUSTOMERS SAY
We are changing the conversation around how paper and packaging is used, innovating to reduce its use. With our ambitious goals around technology and innovation, we seek to responsibly reduce the environmental impact of plastics for our planet and future generations.
CONTACT US NOW AND BOOK A 14 DAY TRIAL
Base Pallet Wrapper | Power Pre-Stretch System
Features:
- 24 hour a day operation.
- Perfect for fast paced operations.
- Supercut: power pre-stretch with auto cut-off system — option.
- Rack and pinion shaft.
- Automatic programming.
- Inbuilt digital technology to calculate usage.
- Chain driven turntable.
- Optional scales system available.
- Maximum loading weight 2,000kg.
This machine is available for purchase or rental. We provide machine parts, maintenance and servicing as well as 5- and 10-year warranty options.
The Base Pallet Wrapper is an award-winning machine that reduces plastic usage and wrapping costs. Its power pre stretch function can stretch pallet wrap film up to 400%. This increases stretch film efficiency.
This heavy-duty pallet wrapper has a chain-driven turntable and rack and pinion mast. These features reduce break downs and makes this a low maintenance and reliable machine. It includes multiple programming to ensure it wraps all pallets with optimum load containment.
We offer 5- and 10-year warranty options on this machine as well as full maintenance and servicing.
- Adjustable power pre-stretch or electromagnetic broke film tension.
- Adjustable parameters: cycle selection, bottom & top laps, top sheet cycle, rotation speed, carriage ascent & descent speed, film tension, starting wrapping height.
- 6 working cycles: ascent/descent; top sheet; only ascent; only descent; layers; stack.
- 3 working modes: semi manual, semi-automatic, fixed height.
- Strengthening operation.
- Wrapped pallet counter.
- Stop at home position.
- Braked turntable at the end of the cycle.
- Standard turntable diameter ø1,650mm.
- Maximum height of pallet: 2,400mm.
- Maximum loading weight: 2,000kg.
- Powder coating.
- Safety stop at the base of the carriage.
- 3 password levels (including lock password).
- Acoustic warning for beginning and end cycle.
- Top-press.
- Adjustable power pre-stretch.
- 3,000mm max. wrapping height.
- Photocell for dark loads.
- Weighing system.
- Mechanical system to brake roll containers.
- Pre-stretch up to 420%.
- Remote control.
- Pit frame.
- Feet under the machine.
- Safety fences.
- Ramp.
- Film edge rollers to improve load containment force.
- IP65.
- Electronic printed circuit board.
- Carriage speed frequency controller.
- Turntable speed frequency controller.
- Photocell for pallet height detection.
- Power board IP54.
- Storage of 32 end user programs.
- Auto diagnostic.
- Receiver for infrared/radio remote control.
